ECUMaster PMU-24 DL

ECUMaster
ECUPMU24DL
Many in stock
$2,049.00
The PMU-24 DL is a new and enhanced Power Management Unit featuring all of the amazing...
Size Guide
$2,049.00

The PMU-24 DL is a new and enhanced Power Management Unit featuring all of the amazing functionality of the PMU-16, now with 24 high-side outputs and internal data logging memory as standard. Through clever engineering, 8 of the analog inputs may be utilized as 7 amp high side outputs. As standard with the PMU-16 series, all output states, voltage, and current information are able to be transmitted via CAN bus to a dash display to inform the driver of potential problems. In addition, all internally logged data can be downloaded from the device for later analysis.

Key Features:

  • 170 Amp continuous current capacity.
  • Operating voltage: 6-22V (immunity to transients according to ISO 7637)
  • Temperature range: AECQ-100 GRADE 1, -40 to +125°C.
  • 10x 25 Amp high-side power outputs (PWM capable).
  • 6x 15 Amp high-side power outputs.
  • 8x 7 Amp high-side power outputs.
  • Up to 16 analog inputs.
  • 24x tricolor LED for each power output state.
  • 2x CAN 2.0 A/B.256 MB data logger memory.
  • Up to 500 Hz logging frequency.
  • Real-time clock for data stamping.
  • 3D accelerometer/gyroscope.
  • Built-in “inertia switch” in case of an accident.
  • Easy access to CAN-bus data (imports and exports).
  • Internal data processing using logical functions, numbers, timers, and tables.
  • Custom PID controllers.
  • Fully customizable ”logic” for each output.
  • Flexible and intuitive client software.

Additional Documents

PMU-24 DL Pinout Simplified

PMU-24 DL Pinout Advanced

PMU User Manual 92.0

PMU Comparison Chart

PMU-24 DL CAD Data

Drawings - PMU-24 DL
